Micronaut Oauth2

Integration between Micronaut, Oauth2 and OpenID Connect

Version: 1.0.0.BUILD-SNAPSHOT

1 Installation

This project eases Oauth 2.0 integration with Micronaut.

compile 'io.micronaut.configuration:micronaut-oauth2:1.0.0.BUILD-SNAPSHOT'
<dependency>
    <groupId>io.micronaut.configuration</groupId>
    <artifactId>micronaut-oauth2</artifactId>
    <version>1.0.0.BUILD-SNAPSHOT</version>
</dependency>

To use the BUILD-SNAPSHOT version of this library, check the documentation to use snapshots.

Code can be found at the micronaut-oauth2 repository.

2 Oauth 2

Micronaut supports integration with authentication & authorization platforms such as Okta, Auth0, AWS Cognito, Keycloak, etc.

Once you create an application client with a provider, you will get a Client ID and optionally a Client Secret.

aws cognito appclient

The previous image shows how to get an client id and client secret with AWS Cognito. Please, note you can obtain similar credentials with other providers.

Once, you get the client_id and client_secret configure the oauth configuration:

🔗
Table 1. Configuration Properties for OauthConfigurationProperties
Property Type Description

micronaut.security.oauth2.client-id

java.lang.String

Oauth 2 Application Client ID.

micronaut.security.oauth2.client-secret

java.lang.String

Oauth 2 Application Client Secret. Optional.

For example, if you configured:

src/main/resources/application.yml
micronaut:
  security:
    oauth2:
      client-secret: '${OAUTH_CLIENT_SECRET}'
      client-id: '${OAUTH_CLIENT_ID}'

You can supply two environment variables OAUTH_CLIENT_SECRET, OAUTH_CLIENT_ID with the credentials you obtained from the provider to be used as values of micronaut.security.oauth2.client-id and micronaut.security.oauth2.client-secret.

3 Open ID Connect

OpenID Connect 1.0 is a simple identity layer on top of the OAuth 2.0 protocol. It allows Clients to verify the identity of the End-User based on the authentication performed by an Authorization Server, as well as to obtain basic profile information about the End-User in an interoperable and REST-like manner.

If you are new to OpenID Connect, watch Oauth 2.0 and OpenID Connect.

4 Service Discovery

The easiest way to integrate a Micronaut application with an Open ID Connect server is to use the .well-know/openid-configuration endpoint, an endpoint which applications use to retrieve the configuration information for the OIDC server.

The endpoint returns a specified set of fields. Micronaut uses the configuration returned to configure itself accordingly.

Please, chek with your provider to locate the location of the .well-know/openid-configuration configuration endpoint. Next, we show examples for common providers:

4.1 Service Discovery with OKTA

src/main/resources/application.yml
micronaut:
  security:
    oauth2:
      client-secret: '${OAUTH_CLIENT_SECRET}'
      client-id: '${OAUTH_CLIENT_ID}'
      openid-configuration: '${OKTA_DOMAIN}/oauth2/${OKTA_AUTHSERVERID}/.well-known/openid-configuration'

You will need to setup the OKTA_DOMAIN and OKTA_AUTHSERVERID environment variables.

Those may be something like:

export OKTA_DOMAIN=https://dev-XXXXX.oktapreview.com
export OKTA_AUTHSERVERID=default

4.2 Service Discovery with AWS Cognito

To configure the .well-know/openid-configuration endpoint with AWS Cognito you can setup:

src/main/resources/application.yml
micronaut:
  security:
    oauth2:
      client-secret: '${OAUTH_CLIENT_SECRET}'
      client-id: '${OAUTH_CLIENT_ID}'
      openid-configuration: 'https://cognito-idp.${AWS_REGION}.amazonaws.com/${COGNITO_POOL_ID}/.well-known/openid-configuration'

Please, note you will need to define environment varaibles for AWS_REGION and COGNITO_POOL_ID.

4.3 Service Discovery with Auth0

src/main/resources/application.yml
micronaut:
  security:
    oauth2:
      client-secret: '${OAUTH_CLIENT_SECRET}'
      client-id: '${OAUTH_CLIENT_ID}'
      openid-configuration: '${AUTH0_DOMAINNAME}/.well-known/openid-configuration'

You will need to define the environment variable AUTH0_DOMAINNAME.

You can obtain the auth0 domain from the application dashboard:

auth0 domain

4.4 Service Discovery with Keycloak

src/main/resources/application.yml
micronaut:
  security:
    oauth2:
      client-secret: '${OAUTH_CLIENT_SECRET}'
      client-id: '${OAUTH_CLIENT_ID}'
      openid-configuration: '${KEYCLOACK_DOMAIN}/auth/realms/${KEYCLOAK_REALM}/.well-known/openid-configuration'

You will need to define the environment variable KEYCLOACK_DOMAIN and KEYCLOAK_REALM for example:

export KEYCLOACK_DOMAIN=http://localhost:8080
export KEYCLOAK_REALM=master

5 Endpoints

5.1 Authorization Endpoint

If you use the Service discovery endpoint some of the configuration values required to communicate with the Authorization endpoint will be inferred from the service discovery endpoint response. For example, you will not need to configure the authorization endpoint’s url since that information is typically returned by service discovery endpoint. However, if the default values do not suffice, you can configure the communication with the authorization endpoint:

🔗
Table 1. Configuration Properties for AuthorizationEndpointConfigurationProperties
Property Type Description

micronaut.security.oauth2.authorization.url

java.lang.String

the authorization endpoint’s url.

micronaut.security.oauth2.authorization.redirect-uri

java.lang.String

Redirection URI to which the response will be sent. Default value (http://localhost:8080/auth/code).

micronaut.security.oauth2.authorization.scopes

java.util.List

Sets Oauth 2.0 scopes. Default value (['openid']).

micronaut.security.oauth2.authorization.response-type

java.lang.String

Set OAuth 2.0 Response Type. Default value ({@value #DEFAULT_RESPONSETYPE}).

micronaut.security.oauth2.authorization.response-mode

java.lang.String

Informs the Authorization Server of the mechanism to be used for returning parameters from the Authorization Endpoint. Default value ({@value #DEFAULT_RESPONSEMODE}).

micronaut.security.oauth2.authorization.display

Display

ASCII string value that specifies how the Authorization Server displays the authentication and consent user interface pages to the End-User. Default value (null).

micronaut.security.oauth2.authorization.prompt

Prompt

Space delimited, case sensitive list of ASCII string values that specifies whether the Authorization Server prompts the End-User for reauthentication and consent. Default value (null).

micronaut.security.oauth2.authorization.max-age

java.lang.Integer

Maximum Authentication Age. Default value (null).

micronaut.security.oauth2.authorization.ui-locales

java.util.List

End-User’s preferred languages and scripts for the user interface. Default value (null).

micronaut.security.oauth2.authorization.acr-values

java.util.List

Requested Authentication Context Class Reference values. Default value (null).

The authorization request is built by default with DefaultAuthenticationRequestProvider. Remember you can always replace that bean and provide your own implementation of AuthenticationRequestProvider.

5.1.1 State

The default implementation does not provide an Authentication Request state parameter.

Opaque value used to maintain state between the request and the callback. Typically, Cross-Site Request Forgery (CSRF, XSRF) mitigation is done by cryptographically binding the value of this parameter with a browser cookie.

However, you can provide a StateProvider bean and it will be included in the authentication request.

To validate the state received in the response provide an implementation of StateValidator bean.

5.1.2 IDToken Hint

The default implementation does not provide an ID Token hint.

A Token previously issued by the Authorization Server being passed as a hint about the End-User’s current or past authenticated session with the Client.

However, you can provide a IdTokenHintProvider bean and it will be included in the authentication request.

5.1.3 Login Hint

The default implementation does not provide an login hint.

Hint to the Authorization Server about the login identifier the End-User might use to log in.

However, you can provide a LoginHintProvider bean and it will be included in the authentication request.

5.1.4 Nonce

The default implementation does not provide an Nonce parameter.

A String value used to associate a Client session with an ID Token, and to mitigate replay attacks.

However, you can provide a NonceProvider bean and it will be included in the authentication request.

5.2 Token Endpoint

If you use the Service discovery endpoint some of the configuration values required to communicate with the Token endpoint will be inferred from the service discovery endpoint response. For example, you will not need to configure the token endpoint’s url since that information is typically returned by service discovery endpoint. However, if the default values do not suffice, you can configure the communication with the authorization endpoint:

🔗
Table 1. Configuration Properties for TokenEndpointConfigurationProperties
Property Type Description

micronaut.security.oauth2.token.url

java.lang.String

token endpoint’s url

micronaut.security.oauth2.token.grant-type

java.lang.String

Oauth 2.0. Grant Type. Default value (authorization_code).

micronaut.security.oauth2.token.auth-method

java.lang.String

Client Authentication method. By default no value is specified. In that case, the value returned by AuthMethodProvider, if such a bean exists, is used.

micronaut.security.oauth2.token.content-type

MediaType

The Content-Type used to communicate with the token endpoint. Default value (application/x-www-form-urlencoded).

micronaut.security.oauth2.token.redirect-uri

java.lang.String

Redirection URI to which the response will be sent.

The authorization request is built by default with DefaultTokenRequestProvider. Remember you can always replace that bean and provide your own implementation of TokenRequestProvider.

5.3 End Session Endpoint

A logout process may look like the one displayed in the next image:

logout diagramm

Ending the session in the authorization server provider is not standard.

Micronaut provides several beans which are loaded by default.

The authorization server’s end session url is provided by an implementation of EndSessionUrlProvider. By default, DefaultEndSessionUrlProvider is used.

Micronaut attempts to create a valid configuration by default but you can always control the end-session endpoint configuration:

However, if the default values do not suffice, you can configure the communication with the authorization endpoint:

🔗
Table 1. Configuration Properties for EndSessionEndpointConfigurationProperties
Property Type Description

micronaut.security.oauth2.end-session.url

java.lang.String

The end-session endpoint url

micronaut.security.oauth2.end-session.redirect-uri

java.lang.String

Redirection URI to which the response will be sent.

micronaut.security.oauth2.end-session.parameters

java.util.List

End-session endpoint parameters.

Several Provider Specific beans related to end session endpoint configuration are provided.

5.3.1 Logout Controller

You will need to enable the Logout Controller and accept GET requests.

src/main/resources/application.yml
micronaut:
    security:
        ...
        ..
        .
        endpoints:
            logout:
                enabled: true (1)
                get-allowed: true (2)
1 Enable Logout Controller.
2 Accept HTTP GET requests to the logout controller endpoint.

5.3.2 Logout URL

If you are using Server side view rendering support in Micronaut, the EndsessionViewModelProcessor injects into the model the logout url of the authorization server correctly configured.

🔗
Table 1. Configuration Properties for EndsessionViewModelProcessorConfigurationProperties
Property Type Description

micronaut.security.oauth2.end-session.view-model-processor.enabled

boolean

Sets whether the {@link EndsessionViewModelProcessor} is enabled. Default value ({@value #DEFAULT_ENABLED}).

micronaut.security.oauth2.end-session.view-model-processor.end-session-url-key

java.lang.String

Model key name. Default value ({@value #DEFAULT_ENDSESSIONURLKEY}).

Next code snippets shows a Velocity view which contains a link to logout.

<!DOCTYPE html>
<html>
<head>
    <title>Logout/title>
</head>
<body>
<a href="${endsessionurl}">Logout</a>
</body>
</html>

6 Provider Specific Beans

Cognito

If the term cognito is present in the value of micronaut.security.oauth2.openid-configuration the next beans are loaded:

If you want to disable that bean you can set micronaut.security.oauth2.token.auth-method-provider.cognito to false

If you want to disable that bean you can set micronaut.security.oauth2..end-session.aws-cognito.enabled to false

Okta

If the term okta is present in the value of micronaut.security.oauth2.openid-configuration the next beans are loaded:

If you want to disable that bean you can set micronaut.security.oauth2.end-session.okta.enabled to false

Auth0

If the term auth0 is present in the value of micronaut.security.oauth2.openid-configuration the next beans are loaded:

If you want to disable that bean you can set micronaut.security.oauth2.end-session.auth0.enabled to false

7 Flows

7.1 OpenID Connect Authorization code Flow

The following configuration illustrates a possible set up to use authorization code flow with Micronaut and a third-party OpenID Configuration authorization server.

src/main/resources/application.yml
micronaut:
    security:
        enabled: true (1)
        oauth2:
          client-secret: '${OAUTH_CLIENT_SECRET}'  (2)
          client-id: '${OAUTH_CLIENT_ID}' (3)
          openid-configuration: '${OKTA_DOMAIN}/oauth2/${OKTA_AUTHSERVERID}/.well-known/ openid-configuration' (4)
        token:
            jwt:
                enabled: true (5)
                cookie:
                    enabled: true (6)
1 Enable security
2 Client Secret. Your authorization server provider provides this value.
3 Client ID. Your authorization server provider provides this value.
4 well-know openid-configuration endpoint url. Allows micronaut to discover the configuration of the Open ID Configuration server.
5 Often, ID Token will be responded as JWT tokens. You will need to enable Micronaut’s JWT support to validate it.
6 Once, validated you may want to save the JWT IDToken in a cookie. To read in subsequent requests, enable Cookie Token Reader.
diagramm

7.1.1 Authorization Code Controller

The AuthorizationCodeController controller handles the response from the Authorization endpoint and it can be configured:

🔗
Table 1. Configuration Properties for AuthorizationCodeControllerConfigurationProperties
Property Type Description

micronaut.security.endpoints.authcode.enabled

boolean

Sets whether the {@link AuthorizationCodeController} is enabled. Default value ({@value #DEFAULT_ENABLED}).

micronaut.security.endpoints.authcode.controller-path

java.lang.String

if the callback endpoint is /authcode/cb controller path will be /authcode. Default value ({@value #DEFAULT_CONTROLLERPATH}).

micronaut.security.endpoints.authcode.action-path

java.lang.String

if the callback endpoint is /authcode/cb controller action path will be /cb . Default value ({@value #DEFAULT_ACTIONPATH}).

7.1.2 ID Token Validator

Assuming the ID Token is a JWT token, the DefaultIdTokenAccessTokenResponseValidator validates the JWT Claims against every bean of type GenericJwtClaimsValidator and IdTokenClaimsValidator.

Some GenericJwtClaimsValidator are already registered:

Some IdTokenClaimsValidator are already registered: and:

Please, validate your IDToken as described in the ID Token Validation section.

Remember to enable JWT support micronaut.security.token.jwt.enabled=true.

7.1.3 Failure Handler

If the validation of the IdTokenAccessTokenResponse, an object which encapsulates the response of the token endpoint, fails a InvalidIdTokenAccessTokenResponseException is raised.

Read Error Handling section in the documentation to handle the exception according to your needs.

7.1.4 Successful ID Token Handler

Once the authentication has been validated, it is to time handle the ID Token. Provide a bean of type: SuccessfulIdTokenAccessTokenResponseHandler

By default, CookieSuccessfulIdTokenAccessTokenResponseHandler is provided which can be configured with:

🔗
Table 1. Configuration Properties for CookieSuccessfulIdTokenAccessTokenResponseHandlerConfigurationProperties
Property Type Description

micronaut.security.oauth2.openid.idtoken.cookie.cookie-name

java.lang.String

Cookie Name. Default value (JWT).

micronaut.security.oauth2.openid.idtoken.cookie.cookie-domain

java.lang.String

Sets the domain name of this Cookie. Default value (JWT).

micronaut.security.oauth2.openid.idtoken.cookie.cookie-path

java.lang.String

Sets the path of the cookie. Default value ({@value #DEFAULT_COOKIEPATH}).

micronaut.security.oauth2.openid.idtoken.cookie.login-success-target-url

java.lang.String

Sets the login success target URL. Default value ({@value #DEFAULT_LOGINSUCCESSTARGETURL}).

micronaut.security.oauth2.openid.idtoken.cookie.cookie-http-only

java.lang.Boolean

Whether the Cookie can only be accessed via HTTP. Default value ({@value #DEFAULT_HTTPONLY}).

micronaut.security.oauth2.openid.idtoken.cookie.cookie-secure

java.lang.Boolean

Sets whether the cookie is secured. Default value ({@value #DEFAULT_SECURE}).

micronaut.security.oauth2.openid.idtoken.cookie.cookie-max-age

java.time.temporal.TemporalAmount

Sets the maximum age of the cookie.

micronaut.security.oauth2.openid.idtoken.cookie.enabled

boolean

Enables CookieSuccessfulIdTokenAccessTokenResponseHandler. Default value ({@value #DEFAULT_ENABLED}).

7.2 Password Grant Type

The Password grant is one of the simplest OAuth grants and involves only one step: the application presents a traditional username and password login form to collect the user’s credentials and makes a POST request to the server to exchange the password for an access token

For example, the next image illustrates a Basic auth authentication which does a remote grant type pasword authentication:

grant type password

You can enable an implementation of Authentication Provider to authenticate using Grant type password.

micronaut:
  security:
    oauth2:
      client-secret: '${OAUTH_CLIENT_SECRET}'
      client-id: '${OAUTH_CLIENT_ID}'
      grant-type-password:
        enabled: true
🔗
Table 1. Configuration Properties for GrantTypePasswordRequestProviderConfigurationProperties
Property Type Description

micronaut.security.oauth2.grant-type-password.enabled

boolean

Sets whether the {@link GrantTypePasswordRequestProvider} is enabled. Default value ({@value #DEFAULT_ENABLED}).

micronaut.security.oauth2.grant-type-password.content-type

MediaType

The Content-Type used to communicate with the token endpoint.

micronaut.security.oauth2.grant-type-password.scopes

java.util.List

OAuth 2.0 scopes.
